Wire Mesh Fencing Manufacturer
6 Years
| Ask Lasest Price | |
| Brand Name : | LNF-Gabion Wire Mesh |
| Model Number : | Gabion For Sale |
| Certification : | ISO |
| Price : | 1.08$-9.88%/SQM |
| Payment Terms : | T/T |
| Supply Ability : | 100000SQM PER WEEK |
| Delivery Time : | 5-8 work days |
Materials:
Low carbon steel wire, stainless steel wire, electro galvanized wire, hot-galvanized wire, heavily galvanized wire, PVC-coated.
Weaving processing: Twisted before galvanized, weaving after galvanized.
Gabion Size:
2m× 1m× 1m, 3m× 1m× 1m, 4m× 1m× 1m, 2m× 1m× 0.5m, 4m× 1m× 0.5m. Customer orders available.
| Gabion Boxes | |||
| Opening (mm) | Wire Diameter (mm) | Wire Diameter (PVC Coated)/ Inner/Outside(mm) | Strands |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 3 |
| 80X100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 80X120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 100X120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 100X150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 120X150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 3 |
Packing: in bundle or pallet or as your requirement
Applications:
The gabion box or gabion basket is unfolded and laid on prepares ground. The kinks and creases in the boxes can be easily stamped out and leveled manually. The individual sheets are straightened flat and then systematically folded to form an exact rectangular shape. All the sides diaphragms are laced with lacing wire with lacing procedure. The boxes or group of laced boxes are positioned at the required location to match the structural design accurately.
|
|
